Digital electric system

SIEMENS 840D+ SIEMEN programmable controller S7-300+10.4〞display adopts advanced CNC control system which has the function of condition control, time limit control, step-by-step control, A / D and D / a conversion, communication, basing on 840D operation system environment, exclusive human-computer interface and shot blasting saturation curve of digital control shot blaster is developed and generated automatically. Which is clear and easy to operate. Electrical control system configures controlling cabinet, S7-300 programmable controller has the function of control, preparation, feeding, self-diagnosis, remote diagnosis, automatic compensation and manual compensation, C-axis error correction, human-computer conversation, online programming, off-line programming and accident date saving.
Operating system software: Windows CC configuration software, display working status of equipment, programming storage hardware and machine tool operating history inquiry, breakdown alarm display, generation of saturation curve of digital control shot blasting, PLC software, monitoring of working status of consumables.

Sinamics S120 driving control system is for the control of whole system and inspection of all kinds of switching value, analog quantity; S120 system FANUC digital control system and AC servo system has the function of controlling and maintaining, monitoring the process of machine tool.

Electrical control cabinet

The guard rate of electrical control cabinet if IP54, has the conditioner humidity removal, installed with maintenance lighting and AV 220V industrial socket.

Control system configures industrial PC host computer to integrate control technology and computer technique, it has the function of date storage, debugging program and net communication.
